用途:

本產品廣泛適用于鞋盒、襯衫盒、內衣盒等天地蓋盒類包裝相關企業。

性能特點：

1、成型粘合速度快，成型質量穩定。

2、成型產品無需晾放，不會對用戶造成場地浪費。

3、結構簡易，操作方便，一般工人可快速上手生產。

4、節省人工、速度快揭，為一般手動粘合成型速度的數倍。

5、節省成本，可大大降低一般手動粘合成型所需膠水。

6、本機可配置流水線大兩快速生產，也可單機自行生產。

主要技術參數：

最大成型紙盒寬度300mm　

最小成型紙盒厚度90mm　

氣壓0.15-1.0mpa　

速度35 times/min　

外形尺寸L1270×W450×H720mm　

機器重量105kg

Usage:

This product is widely applicable to packaging related enterprises such as shoe boxes, shirt boxes, underwear boxes, etc.

Performance characteristics:

1. The molding and bonding speed is fast, and the molding quality is stable.

2. Formed products do not require air drying and will not cause waste of space for users.

3. The structure is simple, easy to operate, and ordinary workers can quickly get started with production.

4. It saves labor and is fast to peel, several times faster than the general manual bonding molding speed.

5. Cost saving can greatly reduce the adhesive required for manual bonding molding.

6. This machine can be equipped with an assembly line for rapid production, or can be produced independently on a single machine.

Main technical parameters:

Maximum formed paper box width 300mm

Minimum formed paper box thickness 90mm

Air pressure 0.15-1.0 MPa

Speed 35 times/min

External dimensions L1270 × W450 × H720mm

Machine weight 105kg
